Channel-S(W-65mm)
Channel-S(W-65mm) - Image 2
Channel-S(W-65mm) - Image 3

Channel-S(W-65mm)

₹7,000.00 – ₹24,000.00 Price excluding GST

-
+
Add to quote
SKU: Pendant/Surface mount luminaire with HPE (High Performance Efficiency) LED (Light Emitting Diode) Colour temperature of 5700/4000/3000 K, CRI > 80, 230 V constant current driver, 70 % of luminous flux after 50,000 operating hours, Energy efficient LEDs, Direct-Indirect light emission, Luminaire profile in aluminium, Polyester White/Black powder coloured coat applied over a 5- stage pre-treatment, Opal APD/micro prismatic type diffuser for a homogenous light distribution, ZHLS (ZERO HALOGEN LOW SMOKE) internal wiring, Sliding fixing wire suspension. Protection class I, IP 40, suitable for temperatures of -10deg to +50deg, MacAdam 3, T.H.D ≤ 10%, driver efficiency ≥ 88%, surge protection of 2.5 kV, with luminous intensity of minimum 100lm/w Light Throw: Direct/Direct-Indirect light emission Optics: Opal APD/Microprismatic diffuser Finish: White/Black Control Gear: Electronic Control Protection W = 65 mm, H = 71 mm, PL max = 1500 mm. Category:

Pendant/Surface mount luminaire with HPE (High Performance Efficiency) LED (Light Emitting Diode) Colour temperature of 5700/4000/3000 K, CRI > 80, 230 V constant current driver, 70 % of luminous flux after 50,000 operating hours, Energy efficient LEDs, Direct-Indirect light emission, Luminaire profile in aluminium, Polyester White/Black powder coloured coat applied over a 5- stage pre-treatment, Opal APD/micro prismatic type diffuser for a homogenous light distribution, ZHLS (ZERO HALOGEN LOW SMOKE) internal wiring, Sliding fixing wire suspension. Protection class I, IP 40, suitable for temperatures of -10deg to +50deg, MacAdam 3, T.H.D ≤ 10%, driver efficiency ≥ 88%, surge protection of 2.5 kV, with luminous intensity of minimum 100lm/w

Light Throw: Direct/Direct-Indirect light emission
Optics: Opal APD/Microprismatic diffuser
Finish: White/Black Control Gear: Electronic Control Protection
W = 65 mm, H = 71 mm, PL max = 1500 mm.

Variant

Channel-S – 112W:56U-56D (L-2364mm), Channel-S – 14W (L-1192mm), Channel-S – 22W (L-1192mm), Channel-S – 24W (L-1000mm), Channel-S – 24W (L-1000mm) – DALI, Channel-S – 24W (L-1000mm) – Prismatic diffuser, Channel-S – 28W (L-1192mm), Channel-S – 28W (L-2364mm), Channel-S – 28W:14U-14D (L-1192mm), Channel-S – 44W (L-2364mm), Channel-S – 44W:22U-22D (L-1192mm), Channel-S – 48W:24U-24D (L-1000mm), Channel-S – 48W:24U-24D (L-1000mm) – DALI, Channel-S – 48W:24U-24D (L-1000mm) – Prismatic diffuser, Channel-S – 56W (L-2364mm), Channel-S – 56W:28U-28D (L-1192mm), Channel-S – 56W:28U-28D (L-2364mm), Channel-S – 88W:44U-44D (L-2364mm)
